    Purism for walls: The pure design of Zehnder Subway is simple pleasure. The radiator impresses with a clear design aesthetic that refuses to compromise. Its distinctive square frame and delicate round tubes combine to create a designer piece that also doubles as a multiple towel rail. Available in almost any colour and finish from the Zehnder colour chart.

    Show more

    Premium Collection

    Zehnder Subway - Electric operation

    We also offer the following technologies

    Hydronic operationDual energy operation

    Benefits

    • Distinctive design ideally blends with modern bathrooms

    • Generous spaces between the tubes convenient for hanging towels

    • Brushed stainless steel version ensures resistance to corrosion

    • Special solutions support a wide range of application, such as room divider

    Show more

    Electric operation

    • User-friendly control device allows simple operation

    • Dry-running protection prevents temperature warning

    • Electric operation provides warm towels and comfortable rooms all year round

    • Increased safety with keylock

    • Easy handling due to control knob for setting the radiator temperature and for operation using its timer function

    • Customisable daily and weekly programmes for convenient, on-demand operation

    • Comes ready-to-plug for easy and quick installation

    • High energy efficiency due to compliance with the European Ecodesign Directive reduces energy costs

    • Flexible control options: control device for wall mounting or base

    • Heat is readily available due to pre-defined timer function

    • Factory-assembled, elegantly integrated electric heating element reduces cost of installation

    • Low energy consumption of only 0.5 W in stand-by mode for increased energy efficiency

    • Maximum surface temperature of 65 °C ensures increased safety (chrome-plated version)

    Colour System

    Zehnder Subway - Electric operation
    Traffic White (9016* / RAL 9016)
    Standard
    Traffic White (9016* / RAL 9016)
    Warm Colors Core
    White Quartz (0521*)
    Pure White (9010* / RAL 9010)
    Cement Grey (7233 / RAL 7033)
    Edelweiss (0067)
    Cream (9001* / RAL 9001)
    Telegrey 4 (7247 / RAL 7047)
    Beige Quartz (0523*)
    Golden Sand (0258)
    Yellow Grey (7234 / RAL 7034)
    Pearl Beige (1235 / RAL 1035)
    Beach Gold (0272)
    Concrete Grey (0265)
    Beige Grey (0267)
    Bronze (0276)
    Brown Quartz (0529*)
    Dark Brown (0270)
    Grey Aluminium (9007*)
    Anthracite (0346*)
    Umbra Grey (7222 / RAL 7022)
    Volcanic (0336*)
    Warm Colors Trends
    Pastel Green (6219 / RAL 6019)
    Reseda Green (6211 / RAL 6011)
    Olive Green (6203 / RAL 6003)
    Terracotta Faded (0299)
    Terracotta (0292)
    Ruby Red (3003* / RAL 3003)
    Cool Colors Core
    White Matt (0556)
    Light Beige (0253)
    Light Grey (0262)
    White Aluminium (9006*)
    Light Jeans (0264)
    Titane (0335*)
    Inox Look (0332*)
    Telegrey 2 (7246 / RAL 7046)
    Blue Grey (7231 / RAL 7031)
    Anthracite Grey (7016* / RAL 7016)
    Black Quartz (0550*)
    Black Matt (0557)
    Traffic Black (9217 / RAL 9017)
    Jet Black (9005* / RAL 9005)
    Cool Colors Trends
    Pastel Blue (5224 / RAL 5024)
    Pigeon Blue (5214 / RAL 5014)
    Gentian Blue (5210 / RAL 5010)
    Sapphire Blue (5203 / RAL 5003)
    Blue Night (0289)
    Traffic White (9016* / RAL 9016)
    White Quartz (0521*)
    Pure White (9010* / RAL 9010)
    Cement Grey (7233 / RAL 7033)
    Edelweiss (0067)
    Cream (9001* / RAL 9001)
    Telegrey 4 (7247 / RAL 7047)
    Beige Quartz (0523*)
    Golden Sand (0258)
    Yellow Grey (7234 / RAL 7034)
    Pearl Beige (1235 / RAL 1035)
    Beach Gold (0272)
    Concrete Grey (0265)
    Beige Grey (0267)
    Bronze (0276)
    Brown Quartz (0529*)
    Dark Brown (0270)
    Grey Aluminium (9007*)
    Anthracite (0346*)
    Umbra Grey (7222 / RAL 7022)
    Volcanic (0336*)
    Pastel Green (6219 / RAL 6019)
    Reseda Green (6211 / RAL 6011)
    Olive Green (6203 / RAL 6003)
    Terracotta Faded (0299)
    Terracotta (0292)
    Ruby Red (3003* / RAL 3003)
    White Matt (0556)
    Light Beige (0253)
    Light Grey (0262)
    White Aluminium (9006*)
    Light Jeans (0264)
    Titane (0335*)
    Inox Look (0332*)
    Telegrey 2 (7246 / RAL 7046)
    Blue Grey (7231 / RAL 7031)
    Anthracite Grey (7016* / RAL 7016)
    Black Quartz (0550*)
    Black Matt (0557)
    Traffic Black (9217 / RAL 9017)
    Jet Black (9005* / RAL 9005)
    Pastel Blue (5224 / RAL 5024)
    Pigeon Blue (5214 / RAL 5014)
    Gentian Blue (5210 / RAL 5010)
    Sapphire Blue (5203 / RAL 5003)
    Blue Night (0289)
    * These colours / surfaces are glossy, all others matt.
    Despite extreme care in the painting process of our radiators, slight colour deviations are possible, depending on the production series and compared to other colour carriers (ceramic, paper, metal, ...) as well as screen display.
    RAL and NCS are manufacturer's designations.

    Technical data

    Electric-only operation

    Model
    SUBE-130-45/GD
    SUBE-130-45/GF
    SUBE-130-60/GD
    SUBE-150-45/GD
    SUBE-150-45/GF
    SUBE-150-60/GD
    SUBE-150-60/GF
    SUBE-180-45/GD
    SUBE-180-60/GD
    SUBE-180-60/GF
    Model
    SUBEC-130-45/GD
    SUBEC-130-45/GF
    SUBEC-130-60/GF
    SUBEC-150-45/GD
    SUBEC-150-45/GF
    SUBEC-150-60/GD
    SUBEC-150-60/GF
    SUBEC-180-45/GD
    SUBEC-180-60/GD
    SUBEC-180-60/GF
    Model
    SUBEI-130-45/GD
    SUBEI-130-60/GD
    SUBEI-150-45/GD
    SUBEI-150-60/GD
    SUBEI-180-45/GD
    SUBEI-180-60/GD
    Painted version
    Model H L Power electric heating element
    mm mm Watts
    SUBE-130-45/GD 1261 450 500
    SUBE-130-45/GF 1261 450 500
    SUBE-150-45/GD 1549 450 600
    SUBE-150-45/GF 1549 450 600
    SUBE-180-45/GD 1837 450 750
    SUBE-130-60/GD 1261 600 600
    SUBE-150-60/GD 1549 600 750
    SUBE-150-60/GF 1549 600 750
    SUBE-180-60/GD 1837 600 900
    SUBE-180-60/GF 1837 600 900
    H = height, L = length
    HT = Total height incl. electric heating element
    Chrome-plated version
    Model H L Power electric heating element
    mm mm Watts
    SUBEC-130-45/GD 1261 450 300
    SUBEC-130-45/GF 1261 450 300
    SUBEC-150-45/GD 1549 450 300
    SUBEC-150-45/GF 1549 450 300
    SUBEC-180-45/GD 1837 450 300
    SUBEC-130-60/GF 1261 600 300
    SUBEC-150-60/GD 1549 600 300
    SUBEC-150-60/GF 1549 600 300
    SUBEC-180-60/GD 1837 600 600
    SUBEC-180-60/GF 1837 600 600
    H = height, L = length
    HT = Total height incl. electric heating element
    Stainless steel version
    Model H HT L Power electric heating element
    mm mm mm Watts
    SUBEI-130-45/GD 1261 1291 450 300
    SUBEI-150-45/GD 1549 1579 450 300
    SUBEI-180-45/GD 1837 1867 450 500
    SUBEI-130-60/GD 1261 1291 600 300
    SUBEI-150-60/GD 1549 1579 600 500
    SUBEI-180-60/GD 1837 1867 600 600
    H = height, L = length
    HT = Total height incl. electric heating element
