Quality Collection

Zehnder
Aura

Hydronic operation
    Get in touch

    Large spaces between the tubes and straight lines. Every detail of Zehnder Aura is perfectly designed with modern bathrooms in mind. The decorative radiator for hot water central heating is available in white and with a high-quality chrome finish.

    Show more

    Quality Collection

    Zehnder Aura - Hydronic operation

    We also offer the following technologies

    Electric operation

    Benefits

    • D-profile header tube creates harmonious design

    • Ample spaces between tubes make cleaning easy

    • Generous spaces between the tubes convenient for hanging towels

    • Elegant design in high-quality chrome

    • Small radiator depth ideal for narrow bathrooms

    Show more

    Hydronic operation

    • Flexible installation through right and left connection options

    • Available with Zehnder Vario connection fitting for an unobtrusive and elegantly concealed connection system

    • Flexible installation due to 50mm centre connections

    Technical data

    Connection to hot water central heating system

    Chrome-plated version
    With 50 mm centre connection
    Model H L Heat output
    75/65/20 °C 70/55/20 °C 70/55/24 °C 55/45/20 °C 55/45/24 °C
    mm mm W W W W
    PBCN-080-045 775 450 206 167 147 106 88
    PBCN-080-050 775 500 230 186 161 119 98
    PBCN-080-060 775 600 271 224 189 145 116
    PBCN-120-045 1217 450 303 245 216 156 129
    PBCN-120-050 1217 500 330 268 232 169 140
    PBCN-120-060 1217 600 390 315 273 201 165
    PBCN-150-045 1469 450 368 298 262 189 157
    PBCN-150-050 1469 500 407 329 284 209 171
    PBCN-150-060 1469 600 481 391 338 248 204
    PBCN-180-045 1856 450 468 379 333 241 200
    PBCN-180-050 1856 500 513 417 360 262 217
    PBCN-180-060 1856 600 607 490 425 312 257
    H = height, L = length
    75/65/20 = Nominal heat output according to EN 442
    Chrome-plated version
    With 50 mm centre connection
    Model H L Heat output
    75/65/20 °C 70/55/20 °C 70/55/24 °C 55/45/20 °C 55/45/24 °C
    mm mm W W W W
    PBCN-080-045-05 775 450 206 – 147 106 88
    PBCN-080-050-05 775 500 229 186 161 119 98
    PBCN-080-060-05 775 600 274 – 198 145 121
    PBCN-120-045-05 1217 450 303 – 216 156 129
    PBCN-120-050-05 1217 500 331 268 232 169 140
    PBCN-120-060-05 1217 600 388 315 273 201 165
    PBCN-150-045-05 1469 450 368 298 262 189 157
    PBCN-150-050-05 1469 500 406 329 284 209 171
    PBCN-180-050-05 1856 500 514 416 360 262 217
    H = height, L = length
    75/65/20 = Nominal heat output according to EN 442
    Painted version
    With 50 mm centre connection
    Model H L Heat output
    75/65/20 °C 70/55/20 °C 55/45/20 °C
    mm mm W W W
    PBN-080-045 775 450 326 268 177
    PBN-080-050 775 500 358 294 194
    PBN-080-060 775 600 418 346 228
    PBN-120-045 1217 450 469 384 250
    PBN-120-050 1217 500 512 418 272
    PBN-120-060 1217 600 598 487 317
    PBN-150-045 1469 450 576 472 307
    PBN-150-050 1469 500 631 514 335
    PBN-150-060 1469 600 740 603 392
    PBN-180-045 1856 450 719 588 382
    PBN-180-050 1856 500 788 643 418
    PBN-180-060 1856 600 662 754 490
    H = height, L = length
    75/65/20 = Nominal heat output according to EN 442
    Painted version
    With 50 mm centre connection
    Model H L Heat output
    75/65/20 °C 70/55/20 °C 55/45/20 °C
    mm mm W W W
    PBN-080-045-05 775 450 326 268 177
    PBN-080-050-05 775 500 357 294 193
    PBN-120-045-05 1217 450 469 384 250
    PBN-120-050-05 1217 500 511 418 273
    PBN-150-045-05 1469 450 576 471 306
    PBN-150-050-05 1469 500 629 514 334
    PBN-180-045-05 1856 450 719 – 382
    PBN-180-050-05 1856 500 786 643 417
    H = height, L = length
    75/65/20 = Nominal heat output according to EN 442
